Specifications

Splicing Method	Core Alignment DWACAS(Digital Wavelength Automatic Core Alignment System)
Average Loss	SM(0.02dB) / MM(0.01dB) / DS(0.04dB) / NZDS(0.04dB) / G.657(0.02dB)
Return Loss	>>60dB
Splice Time	9s average SM / SM 7s Quick mode
Electrode Lifespan	>3,500 arcs
Applicable Fiber	SM(ITU-TU.625, MM(ITU-TU.651), DS(ITU-T G.653), NZDS(ITU-T.655), G657A, G657B 0.25mm,0.9mm, 2.0mm, 2.4mm, 3.0mm, FLAT(indoor cable)
Cleaved Length	Coating Diameter 0.25mm = 16mm minimum
Coating Diameter	100-1,000um
Cladding Diameter	80-150um
Heating Programs	Factory installed mode : 9, User installable mode : 23
Heating Time	Typical 18s
Protection Sleeve	40mm, 60mm, SOC Connector
Data Output	HDMI
Splice Programs	Factory installed mode: 33, User installable mode: 70+
Splice Memory	Up to 2,000 records and 2,000 splice images
Battery	Typical full cycle 130 Splice and Heat / 3000mAh X 2EA
Power Supply	AC 100-240V input or DC 9~14V
Monitor	Color 4.3’’ LCD monitor, with Touch Screen
Cameras	2 CCD camera system
magnification	XY style : 150 power, X/Y : 300 power
Fiber Display	X/Y or XY, single X.Y
Weight	1.44Kg (without battery)
Size	124mm X 123mm X 130 mm
Wind Protection	The max wind speed 15m/s
Operating Environment	Elevation 0-5,000 meters, -40~80˚C, 0~95% relative humidity
Storage Condition	Temperature -40 to 80˚C, 0~95% relative humidity, battery -20~30˚C
Pull Test	1.96~2.25N (standard)
